USAAM80-10 TURBO SEGMENTED DIAMOND BLADE
USAAM80-10 TURBO SEGMENTED DIAMOND BLADE
USAAM80-10 TURBO SEGMENTED DIAMOND BLADE
Product Made in USA

EN13236

Product Logo

USAAM80-10 TURBO SEGMENTED DIAMOND BLADE

Asphalt & Abrasive Materials

600 Pro

Asphalt
Green Concrete
Abrasive Stone
Soft Stone
Abrasive Blocks
Wet Cutting
Dry Cutting
2x Laser Welded

Cat® Asphalt / Abrasive blades are designed for intensive use across the 3 performance grades: Good, Better and Best. Each individual product has specifically designed segments shape and geometry which complements the diamond grit and bond formulation that is proved to enhance the cutting performance in terms of fluidity and smoothness of cut, speed and blade life. Cat® Asphalt / Abrasive blades are able to cut all types of asphalt and abrasive materials. Each increase in performance rating increases the performance in terms of speed and life by use of higher diamond quality and diamond concentration, bond formulation and segment height. All blades have special undercut protection segments for clearing debris from the cut alleviating undercutting of the segments.

Attributes

  • HIGH DIAMOND CONCENTRATION & DIAMOND QUALITY
  • UNDERCUT PROTECTION SEGMENTS TO CLEAR DEBRIS
  • FULLY HARDENED & HEAT TREATED STEEL CORE
  • LONG LIFE, GOOD SPEED OF CUT, WIDEST APPLICATION SPAN
  • ABOVE INDUSTRY STANDARD DIAMOND QUALITY & BOND FORMULATION
  • 2X LASER WELDED FOR SAFETY & STABILITY OF SEGMENTS
  • KEYHOLE GULLET DESIGN FOR DUST EXTRACTION FROM CUT.

To see the full product details table, please rotate your device.

Product Type Diameter Segment Height Segment Width Main Arbor - Bore Reducing Rings Included Machines Used
See Key
Part No Code No MM Inch MM Inch MM Inch MM Inch MM Inch
DA33622U USAAM801210 300 12 10 0.394 3.175 0.125 25.4+P 1+P 20mm 0.78 High Speed SawFloor SawLow HP Walk-BehindGreen Concrete SawTable SawBrick Saw
DA33623U USAAM801410 350 14 10 0.394 3.175 0.125 25.4+P 1+P 20mm 0.78 High Speed SawFloor SawLow HP Walk-BehindGreen Concrete SawTable SawBrick Saw
DA33624U USAAM801610 400 16 10 0.394 3.175 0.125 25.4+P 1+P 20mm 0.78 High Speed SawFloor SawLow HP Walk-BehindGreen Concrete SawTable SawBrick Saw
DA33625U USAAM801810 450 18 10 0.394 3.175 0.125 25.4+P 1+P 20mm 0.78 High Speed SawFloor SawLow HP Walk-BehindGreen Concrete SawTable SawBrick Saw

Available in USA, non-oSa accredited.

Application

ASPHALT, CONCRETE BLOCK UNDER 15N/MM², THERMAL BLOCK 7 N/MM², GREEN CONCRETE UNIVERSAL, GREEN CONCRETE WITH VERY HARD AGGREGATE, GREEN CONCRETE WITH MEDIUM HARD AGGREGATE.

LIGNACITE BLOCKS, LAVA ROCK, PUMICE

ASPHALT OVER CONCRETE.

SOFT FACING BRICKS

Key

Correct bond for application optimal performance, speed & life

Good match bond for application excellent performance speed & life

Acceptable bond for application reduced performance, speed & life

Occasional use only - much reduced performance, speed & short life - glazing & premature wear will occur
